Electrical
Voltage: 30 Volts DC
Current Rating: 0.5 Amperes (per pin)
Contact Resistance: 50 mΩ max.
Dielectric Withstanding Voltage: 500V AC for 1 minute
Insulation Resistance: 100MΩ min.
Operating Temperature: -30°C ~ +85°C
Reference
Specification(Abbreviation)
Type: Plug
Pitch(mm): 0.8
PCB Mounting: SMT
Operation Direction: D/R S/T
Product Height (mm): 26.6
Mating Height (mm): 28
Mates With: 110-10008-xxx
Circuits: 64
High Speed Support: PCIe Gen 3(8GT/s)
