Electrical
Voltage: 50V AC(Per Pin)
Current: AWG#28/1.5A
Contact Resistance: 55mΩ max (INITIAL).
Dielectric Withstanding Voltage: 500V AC MIN
Insulation Resistance: 100MΩ min.
Operating Temp : -40℃~ +85℃
Specification(Abbreviation)
Family: Wafer
Pitch (mm): 1.25
PCB Mounting: SMT
Operation Direction: S/R S/T
Product Height (mm): 4.15
AWG#: 28
Current (A): AWG#28/1.5A
Outer Lock: Yes
Circuits: 12
Download > 3D
12Download
2D
SPEC
3D
