51982-xxxxx-xxx

Electrical

Voltage: 30V AC(Per Pin) Mated P/N:
Current: 5.0A (Per Pin)
Contact Resistance: 20mΩ max.
Dielectric Withstanding Voltage: 500V AC/rms
Insulation Resistance: 500 MΩ min.
Operating Temp : -40℃~ +85℃



Specification(Abbreviation)

Family: Blade Male

Pitch(mm): 2.00

PCB Mounting: T/H

Operation Direction: R/A

Above PCB Height (mm): 4.00

Current(A): 5.0

Screw (Yes/No): No

Circuits: 7
