52900-xxxxxxx-xxx

Electrical

Voltage: 600 Volts AC (per pin)
Current: 35 Amperes (per power pin)
Contact Resistance: 1 mΩ max.
Dielectric Withstanding Voltage: 2500 VAC /rms
Insulation Resistance: 5000MΩ min.
Operating Temp. : -40℃ ~ +125℃

Reference

Mated P/N : 52901



Specification(Abbreviation)

Family: Power Access

Pitch(mm): 6.35/2.54

PCB Mounting: T/H,Post

Operation Direction: R/A

Mates With: 52901
