52953-XXXXX-XXX

Electrical

Voltage: 250 Volts AC (Per Pin)
Current: 40 Amperes (Per Power Pin)
Contact Resistance: 40 mΩ max.
Dielectric Withstanding Voltage: 1500V AC/rms
Insulation Resistance: 5000MΩ min.
Operating Temp. : -40℃ ~ +125℃



Specification(Abbreviation)

Family: Power Card Edge

Pitch(mm): 2.50, 0.75

PCB Mounting: T/H

Operation Direction: S/T

High Speed Support: SAS 3(12Gbps)
